CLASSIFICATION
PRODUCT MODEL:PBM30-12Z-F-DG3-S0
PBM30-12Z-F-DG3-S0
PRODUCT SPECIFICATION:
Rating:5A 250VACmax;:2A 36VDCmax;
Contact Resistance:50mΩ Max.;
Dielectric Strength:1000VAC for 1 Minute
Total Travel:2.8±0.5mm;
Operating Force:600±200gf;
Meachanical Life:200,000Cycles
Load Life:50,000 cycles;
Operating Temperature:-20°C ~70°C;
Function:Momentary ON-OFF
Application：
? Outdoor Controls ·戶外控制
? Security Equipment ·安全設備
? Medical Equipment ·醫療設備
? Food Processing Equipment ·食品加工設備
? Military Equipment ·軍用設備
? Industrial Machinery ·工業機械
? Transportation: Mass-Transit, Lift Trucks
·運輸: 大眾運輸, 起重卡車
DRAWING
ORDER CODING DIAGRAM
