產(chǎn)品規(guī)格：
Circuit :SPST 1P1T withLED
Current Rating :50mA
Voltage Rating :28VDC
Dielectric withstanding voltage :250VAC for 1 minute
Contact Resistance :50mΩ Max .(intial)
Insulation Resistance :500MΩ Min.
Operating Force :250±50gf or 150±50gf
Total Travel :1.5±0.3mm
Opearating :500,000 Cycles Min
Soldear Specifications :260C for 3 Seconds
Function :Momentary
Openrating Temperature :-25°C~ +50°C
應用領域：
Audio / Visual 音響/視聽設備
Computer Peripherals 電腦外設
Consumer Electronics 消費類電子
Instrumentation 儀器儀表
Telecommunication 電信，通信設備
Medical Equipmen 醫(yī)療設備
