產品規格：
Circuit :SPST
Curent Rating :50mA
Voltage Rating :5-24VDC
Dielectric withstanding vltage:500VAC for 1 minute
Contact Resistance :100mΩ Max .(intial )
Insulation Resistance :100MΩ Min.
Operating Force :160±50gf or 230±50gf
Total Travel :0.25±0.1mm
Opearating life :300,000 Cycles Min
Soldear Specifications :260°C for 3 Seconds
Function :Momentary
Openrating Temperature :-20°C~+70°C
應用領域：
Audio / Visual 音響/視聽設備
Computer Peripherals 電腦外設
Consumer Electronics 消費類電子
Instrumentation 儀器儀表
Telecommunication 電信，通信設備
Medical Equipmen 醫療設備
